阿普奇 IPC200-H470 | 工控機/2U上架式工控機/Intel 10~11th桌面CPU

阿普奇 IPC200-H470 | 工控機/2U上架式工控機/Intel 10~11th桌面CPU

特點:

  • 支持Intel? 10/11th Generation Core/Pentium/Celeron Desktop CPU
  • 全套模具成型，標準19英?2U上架式機箱
  • 安裝標準ATX主板，支持標準2U電源
  • 最多支持7槽位半高卡擴展，滿足多行業應用需求
  • 人性化設計，機箱前置系統風扇免工具維護
  • 最多可選4個3.5英寸抗震抗沖擊硬盤位
  • 前?板USB、開關機設計，電源及存儲狀態顯?，更易于系統維護

  • 遠程管理

    遠程管理

  • 狀態監控

    狀態監控

  • 遠程運維

    遠程運維

  • 安全控制

    安全控制

掃碼即可添加微信，售前客服為您提供咨詢服務

產品介紹

工程圖紙

下載產品資料

掃碼添加微信，獲取最新產品資料文件

Model

IPC200-H470

Processor System

 CPU Support Intel??10/11th Generation Core / Pentium/ Celeron Desktop CPU
? TDP 125W
? Socket LGA1200
? Chipset H470
? BIOS AMI 256 Mbit SPI

Memory

 Socket 2 * Non-ECC U-DIMM Slot, Dual Channel DDR4 up to 2933MHz
? Capacity 64GB, Single Max. 32GB

Graphics

 Controller Intel? HD Graphics

Ethernet

 Controller 1 * Intel i225-V LAN Chip (10/100/1000/2500 Mbps, RJ45)
1 * Intel i219-LM GBE LAN Chip (10/100/1000 Mbps, RJ45)

Storage

 SATA 3 * SATA3.0 7P Connector
? M.2 1 * M.2 Key-M Slot (PCIe 3.0 x4 + SATA 3.0, NVMe/ SATA SSD Auto Detect, 2242/2260/2280)

Expansion Slots

 PCIe 1 * PCIe x16 slot (Gen 3, x16 signal)
1 * PCIe x4 slot (Gen 3, x1 signal)
1 * PCIe x4 slot (Gen 3, x1 signal)
? PCI 4 * PCI slot
? Mini PCIe 1 * Mini PCIe (PCIe 3.0x1+USB 2.0, with 1 * SIM Card slot)

Front I/O

 Ethernet 2 * RJ45
? USB 4 * USB 5Gbps (Type-A, 5Gbps, 2 ports for a total of 3A)
2 * USB2.0 (Type-A, 2 ports for a total of 2A)
? PS/2 1 * PS/2 (Keyboard & Mouse)
? Display 1 * DVI-D: max resolution up to 1920*1200 @ 60Hz
1 * HDMI1.4: max resolution up to 3840*2160 @ 30Hz
? Audio 3 * 3.5mm Jack (Line-out + Line-in + MIC)
? Serial 2 * RS232/422/485 (COM1/2, DB9/M, Full Lanes, BIOS Switch)

Rear I/O

 USB 2 * USB2.0 (Type-A)
? Button 1 * Power Button
? LED 1 * Power status LED
1 * Hard drive status LED

Internal I/O

 USB 2 * USB 5Gbps (F_USB3, wafer)
1 * USB2.0 (USB2_1, Vertical type connector)
2 * USB2.0 (F_USB2_1, header)
? COM 4 * RS232 (COM3/4/5/6, Header, Full Lanes)
? Display 1 * VGA: max resolution up to 1920*1200 @ 60Hz (wafer)
1 * eDP: max resolution up to 1920*1200 @ 60Hz (Header)
? Audio 1 * Front Audio (Line-Out + MIC, Header)
1 * Speaker (3W (per channel) into a 4Ω Loads, wafer)
? GPIO 1 * 16 bits DIO (8DI and 8DO, wafer)
? SATA 3 * SATA 7P Connector
? LPT 1 * LPT (Header)
? FAN 2 * SYS FAN (Header)
1 * CPU FAN (Header)

Power Supply

 Type 2U FLEX
? Power Input Voltage AC power supply, voltage and frequency shall be based on the 2U power supply provided
? RTC Battery CR2032 Coin Cell

OS Support

 Windows Windows 10/11
? Linux Linux

Watchdog

 Output System Reset
? Interval Programmable 1 ~ 255 sec

Mechanical

 Enclosure Material SGCC+AL6061
? Dimensions 482.6mm(L) * 475.7mm(W) * 88.1mm(H)
? Mounting Rack-mounted/Desktop

Environment

 Operating Temperature 0 ~ 50℃
? Storage Temperature -20 ~ 70℃
? Relative Humidity 10 to 95% RH (non-condensing)

圖片1 圖片2 圖片3
